Brand:
Asus

CPU Support:

• Intel® Socket LGA1700 for 13th Gen Intel® Core™ Processors & 12th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors (Refer to www.asus.com for CPU support list)
• Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0 (Max Technology 3.0 support depends on CPU types)

Chipset:
Intel® Z790 Chipset

Ethernet:

• 1 x Intel® 2.5Gb Ethernet
• ASUS LANGuard

Wireless:

• Wi-Fi 6E, 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
• Supports 2.4/5/6GHz frequency band (WiFi 6E 6GHz regulatory may vary between countries)
• Bluetooth® v5.3 (Refer to Wi-Fi module manufacturer's website for latest specifications)

USB Ports:

• Rear USB (Total 12 ports):
  • 2 x Thunderbolt™ 4 ports (2 x USB Type-C®)
  • 6 x USB 3.2 Gen 2 ports (5 x Type-A + 1 x USB Type-C®)
  • 4 x USB 3.2 Gen 1 ports (4 x Type-A)
• Front USB (Total 9 ports):
  • 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C® with up to 60W PD/QC4+)
  • 2 x USB 3.2 Gen 1 headers (support additional 4 USB 3.2 Gen 1 ports)
  • 2 x USB 2.0 headers (support additional 4 USB 2.0 ports)

Memory Slots Support:

• 4 x DIMM, Max. 128GB, DDR5 7800+(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800MHz
• Non-ECC, Un-buffered Memory, Dual Channel Memory Architecture
• Supports Intel® Extreme Memory Profile (XMP)
• (Supported memory types, data rate (Speed), and number of DRAM modules vary depending on CPU and memory configuration. Refer to www.asus.com for memory support list)

Internal I/O Connectors:

• Fan and Cooling Related:
  • 1 x 4-pin CPU Fan header
  • 1 x 4-pin CPU OPT Fan header
  • 1 x 4-pin AIO Pump header
  • 4 x 4-pin Chassis Fan headers
  • 1 x W_PUMP+ header
  • 1 x 2-pin Water In header
  • 1 x 2-pin Water Out header
  • 1 x 3-pin Water Flow header
• Power Related:
  • 1 x 24-pin Main Power connector
  • 2 x 8-pin +12V Power connectors
  • 1 x 6-pin PCIe Power connector
• Storage Related:
  • 3 x M.2 slots (Key M)
  • 6 x SATA 6Gb/s ports
• USB:
  • 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C®)
  • 2 x USB 3.2 Gen 1 headers (support additional 4 USB 3.2 Gen 1 ports)
  • 2 x USB 2.0 headers (support additional 4 USB 2.0 ports)
• Miscellaneous:
  • 3 x Addressable Gen 2 headers
  • 1 x AURA RGB header
  • 1 x FlexKey button
  • 1 x Front Panel Audio header (AAFP)
  • 1 x Start button
  • 1 x ReTry button
  • 1 x 10-1 pin System Panel header
  • 1 x Thermal Sensor header
  • 1 x CPU Over Voltage jumper
  • 1 x Alternative PCIe Mode switch

Expansion Slots:

• Intel® 13th & 12th Gen Processors:
  • 2 x PCIe 5.0 x16 slots (support x16 or x8/x8 modes)
• Intel® Z790 Chipset:
  • 1 x PCIe 4.0 x16 slot (supports x4, x4/x4 modes)

Graphics Device:

• 1 x HDMI® port (Supports 4K@60Hz as specified in HDMI 2.1)
• 2 x Intel® Thunderbolt™ 4 ports (USB Type-C®) support DisplayPort 1.4 and Thunderbolt™ video outputs (VGA resolution support depends on processors' or graphic cards' resolution)

Sound:

• ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082
  • Supports jack-detection, multi-streaming, and front panel jack-retasking
  • High-quality 120 dB SNR stereo playback output and 113 dB SNR recording input
  • Supports up to 32-Bit/384 kHz playback
• Audio Features:
  • SupremeFX Shielding Technology
  • ESS® ES9218 QUAD DAC
  • Gold-plated audio jacks
  • Rear optical S/PDIF out port
  • Premium audio capacitors
  • Audio cover

Operating System Support:
Windows® 11, Windows® 10 64-bit

Form Factor:
ATX Form Factor, 12 inch x 9.6 inch (30.5 cm x 24.4 cm)

Warranty:
2 Year Warranty
